Trim-Fast™: Overview
Device Technologies Free Sample Kit

   Trim-Fast Edge Protection

A better, cleaner and faster way to protect your critical equipment from wire and cable abrasion.
Wide range of profiles available off the shelf.
US made and USA content compliant.

Available in a variety of materials:
flexible steel or stainless steel substrate encapsulated with a Silicone, EPDM or PVC extrusion for fast and easy assembly.

Features

  • Excellent grip strength
  • Excellent resistance to abrasion, water absorption, and low and high temperatures
  • Indoor or outdoor use
  • Fast assembly without the use of adhesives, rivets or screws
  • Multi-axis flexibility for small inside and outside radius corners
  • Panel thickness range:  .029 (7.4mm) to .750 (19.1mm)
  • Packaging: 100 foot box, or customer specified length
  • Diagonal cutters

Applications

  • Aerospace
  • Automotive
  • Rail
  • IT/Telecommunication
  • Construction, Mining and Forestry
  • General industrial: Boating, Golf Carts, Helmets etc.
  • Food Industry (FDA white)

“S” Silicone Series:

  • FDA approved (White Silicone Material)
  • ASTM E 662 (Toxicity)
  • ASTM C 542 & ASTM C 1166 (Flame Propagation)

“S” EPDM Series:

  • FMVSS 302 (Flammability of Interior Materials)
  • SAE J1885 (Interior Weatherometer)
  • SAE J1960 (Exterior Weatherometer)
  • SAE 200 M8BA 708 B13 21-6 (Low Temperature Flexibility)

“S” PVC / EPDM Series:

  • Greater flexibility for small corner radii
  • Smaller Profile
Trim-Fast™
Trim-Fast™
Trim-Fast™
